Proximity and directional alerting
Alerts as the worker approaches an energized source and shows which direction it is in. Urgency rises as the distance closes.
Compass Series · AWARENESSStandalone
Essential hazard awareness at the point of work.
The entry point to the Compass Series. A hard hat voltage and current detector that puts proximity and directional alerts in the worker’s peripheral vision, with very little to configure and nothing to administer across a fleet.
Not every crew needs a connected platform on day one. G2 does one thing well: it puts a dependable signal in the worker’s peripheral vision before an energized source is close enough to matter. There is very little to configure and nothing to administer across a fleet.
Alerts as the worker approaches an energized source and shows which direction it is in. Urgency rises as the distance closes.
Mounts on the hard hat brim, in front of the worker’s face. No looking down at a screen or a belt-mounted tool.
Power on, verify against a known source, work. No range to select and no fleet configuration profile to maintain.
Unaffected by the consolidated sensitivity release, so G2 and Pro units share one fleet without a second training track.
| Enclosure | 3.5 × 1.2 × 0.4 in (88.9 × 30.48 × 10.16 mm), polycarbonate, IP-67, flame retardant (UL 94 V-0 at 1.5 mm) |
|---|---|
| Weight | 0.78 oz (22.1 g) |
| Operating temperature | -20 °C to 60 °C (-4 °F to 140 °F); do not charge below 0 °C (32 °F) |
| Humidity | Max. 90% non-condensing at 25 °C |
| Battery | Rechargeable Li-Po, 3.7 V / 250 mAh |
| Typical battery life | 10+ days (80+ hours of use), varies with the number of alerts |
| Charge time | To 100% in 1.5 hours on a USB 2.0 Micro-B (5 V) charger |
| Frequency | 50 Hz and 60 Hz options available |
| Voltage coverage | High Voltage model: 2,400 VAC to 35 kVAC RMS line to neutral, up to 500 kVAC. Low Voltage model: 120 VAC to 2,400 VAC RMS line to neutral. Detection distances vary with conditions, settings and model. |
| Detection sensitivity | Seven sensitivity levels plus Smart Adaptive mode |
| Directional accuracy | Approximately ±20° to a point source |
| Certifications | CE (RoHS, WEEE, 2006/66/EU Battery Directive) |
| Standards | EMC: EN 61326-1:2013 Class B, CISPR 11:2015+A1:2016. Safety: EN 61010-1. IEC TR 61243-6 (Type I). ANSI/ISEA Z89.1-2014 Class E hard hat, full brim, Type 1 (tested accessory). ASTM F3283/F3283M-18. |
| Mounting | Hard hat brim (primary); hot stick adapter for use as a handheld NCVD |
| Part number | Description |
|---|---|
| M01001 | Compass G2 unit, 60 Hz |
Hard hat brim as standard, plus non-brimmed helmet, Petzl Vertex, IDRA 2, adhesive, and SECRA-1 adapters, and hot stick, wrist, and collapsible handheld options.
Yes. Compass G2 remains on sale and is fully supported alongside Compass Core, Compass Pro, and Compass Pro IS.
No. The consolidated 22-setting sensitivity scale and the two adaptive modes introduced in the Consolidated Range Release apply to connected Compass Pro and Compass Pro IS units. Compass G2 is not affected and its alerting behavior does not change.
Compass Core is the full-range model with the fewest settings in the connected lineup: it covers 120 V to 500 kV AC, pairs with Navigator Mobile, and offers two voltage sensitivity settings. Compass G2 is a standalone detector that stays focused on essential worker-level detection with less to configure.
On the brim of a hard hat, centered and forward so the device sits in the wearer’s peripheral vision. For helmets without a traditional brim, use an approved helmet adapter. Incorrect mounting increases false alarms and creates a false sense of detection coverage.
No. Compass Pro IS is the model that carries the UL, CSA, and IEC 60079 intrinsic safety approvals required for classified flammable gas and vapor areas.
Request a walkthrough and we'll show how Compass G2, Compass Core, Compass Pro, and Compass Pro IS scale from essential awareness to full connected safety in flammable environments, tailored to your crews and field conditions.
